Rich experience in industry applications
5 years actuator for solar trackers. More than 300,000 actuators are used in solar trackers. More than 10GW of solar power plants are powered by Tomuu actuators.
Strong supply chain integration
Actuator assembly workshop, household application actuator assembly workshop, die casting workshop, motor assembly workshop, gear assembly workshop.
Quick response
Tomuu has a production capacity of 1500pcs industrial actuators and 5000pcs of home application actuators, through which we can easily adjust the production to meet the needs of our customers.
Deep customization
Tomuu has a professional R&D team to help customers develop actuators that meet their needs.
Related Products
More items about pump component
We Have The Best Solutions for Your Business
HXSEALS Industry Co., Ltd. established in 2010 at Hongkong, engaging in designing and manufacturing all kinds of mechanical seals, pumps agency and sealing materials under the brand "HXSEALS" .We have passed the IS09001 : 2015 quality system certificate and own advanced inspection equipment. Additionally, we strictly insist on the quality principle of "technical innovation, quality products, reliable service, continuous improvements and customer satisfaction" , keeping the way of making professional industrial products.
HXSEALS products are widely used in the fields of food, wastewater, pharmacy and chemical. Modular design is the core of HXSEALS products. Basically, many products have inner connection which could be replaced. Besides of standard products, we could design and manufacture items as well according to your drawings and samples thanks to its professional engineers and technicians.
HXSEALS constantly explores new products and sealing products in order to compass professional industrial products around the world.
Pump components need to be purchased with quality assurance
The quality selection of pump components must be high-quality, because the relative friction between the liquid conveyed by the pump and the pump body will cause wear and tear during the use of the pump. Due to the corrosive nature of the liquid, cavitation and mechanical wear and other reasons, wear and tear can also be caused, so it is necessary to choose high-quality when purchasing.
Working principle of pump
The impeller is installed in the pump casing and fastened on the pump shaft. The pump shaft is directly driven by the motor. There is a liquid suction pipe in the center of the pump casing. The liquid enters the pump through the bottom valve and suction pipe, and the liquid outlet on the pump shell is connected with the discharge pipe.
Function of pump assembly
Function of pump component
Function of suction part: the suction part is located in front of the impeller, and its function is to guide the liquid into the impeller smoothly.
Role of impeller: impeller is the most important working element of pump and the heart of flow passage components. Its function is to convert mechanical energy into liquid energy.
The function of the export part: the export part is located at the periphery or rear of the impeller. Its function is to collect and export or import the liquid flowing from the impeller into the next stage impeller, and convert part of the velocity energy of the liquid into pressure energy.
The role of supporting parts: enable the impeller to rotate and work, and bear some axial and radial forces.
The function of shaft seal components: prevent the leakage of high-pressure liquid in the pump or prevent air from entering the pump.
What are the rotor pump components?
Rotor Pump Component is a deformation of internal gear pump, mainly composed of inner rotor, outer rotor, pump casing, pump cover and so on. The inner rotor of the rotor pump is an external gear, and the outer rotor is an inner gear. The inner and outer rotors are not concentric and have a certain eccentricity. Generally, the number of teeth of the inner rotor is 6, 8, 9, 10, etc., while the outer rotor has one more tooth than the inner rotor. The more teeth of the inner rotor, the smaller the oil pulsation.
User Reviews
What users say about HXSEALS
Frequently Asked Question
Do you have any question?
1. If there is any small failure of the pump, remember not to let it work. If the packing of the pump shaft is worn out and added in time, if the pump continues to be used, the pump will leak.
2. Strong vibration occurs during the use of the water pump, which must be stopped and checked, otherwise it will also cause damage to the water pump.
3. The water pump must pay attention to maintenance after use, for example, when the water pump is used up, the water in the pump should be cleaned, it is best to remove the water pipe and then rinse it with clean water.
4. The tape on the water pump should also be removed, and then rinsed with water and dried in a light place, do not put the tape in a dark and humid place. The tape of the pump must not be stained with oil, let alone apply something sticky to the tape.
1. Check whether all screws and nuts are loose.
2. Change the oil of the gearbox once, and fill the gear oil to the center of the gearbox oil label.
3. Check whether the coupling is clean and free of bruises, and check the concentricity of the coupling.
The basis of pump selection shall be considered from the aspects of process flow, water supply and drainage requirements, and five aspects shall be considered from liquid conveying capacity, equipment lift, liquid property, pipeline layout and operating conditions.
1. The colloid mill flow is one of the important performance data of the pump.
2. The head required by the equipment system is another important performance data of the selected pump, which is usually used to select a margin of 5% to 10% of the pump magnification.
3. Liquid properties, including liquid medium name, physical properties, chemical properties and other properties, physical properties and temperature density D, C u viscosity, solid particle diameter and gas medium, etc., are related calculations for the total system.
4. The pipeline layout condition of the device system refers to the liquid conveying liquid at the liquid delivery height, such as the lowest level of the absorption side, such as the highest level of the discharge side length.
5. The contents of operating conditions, such as the operation of saturated steam force P of liquid, pressure PS at suction side, pressure vessel PZ at exhaust side, altitude, ambient temperature gap or continuous operation, and the position of pump is fixed or portable.
